Mobile cone crusher
ASTON Mobile Cone Crusher: Precision Secondary Crushing & High-Cubical Yield
Built to excel in secondary and tertiary reduction, the ASTON mobile cone crusher transforms pre-crushed materials into premium, uniformly shaped aggregates. Engineered for rapid site deployment, this versatile unit provides an agile processing solution for hard rock quarrying, high-standard road construction, and industrial mineral processing.
Constructed on a heavy-duty mobile chassis, the plant ensures stable site relocation and effortless adaptation to changing working faces. Powered by a high-efficiency hydraulic cone host, it utilizes advanced inter-particle (laminated) crushing technology. Combined with automatic hydraulic adjustment and iron-release protection, the system guarantees consistent particle size distribution, exceptional cubical product quality, and uninterrupted performance even when handling highly abrasive rocks.
Acting as the critical fine-reduction node in crushing circuits, this mobile cone crusher accepts feed directly from primary jaw units and outputs tight-spec aggregates to downstream screening stations. Its optimized closed-circuit capability and intelligent load monitoring maintain balanced material flow, preventing system overloads and maximizing the daily yield of high-value final products.
Feed specifications & finished aggregate output
Feeding size: ≤400mm
Finished products size: 18~40mm
Capacity: 100-500t/h
Coarse stone
Middle size stone
Fine stone
Application field of mobile cone crusher
Material
Ideal for manufactured sand production and fine aggregate shaping from quartz-rich river pebbles, hard rocks (granite, basalt, diabase, andesite), limestone, ore tailings, and crushed stone chips. It consistently produces well-shaped, cubical aggregates that meet strict concrete and asphalt specifications.
Application
Mainly used in highways, railways, airport runways, mines, coal mines, construction, garbage and construction waste recycling, hydropower projects, urban infrastructure, roads or construction sites and other operations that need to be relocated and have strong mobility.
Mobile cone crusher features:
- Excellent mobility: Each crushing module is independently mounted on a compact chassis. Featuring a short wheelbase and tight turning radius, the plant can be easily transported via highway and flexibly maneuvered across rugged crushing sites.
- Hydraulic support legs: Equipped with heavy-duty hydraulic landing legs, the system allows for rapid setup, convenient operation, and rock-solid stability during site relocation and production.
- Integrated return conveyor: Features an automatic, foldable return conveyor for recirculated material, simplifying field installation and accelerating overall setup time for operators.
- Superior crushing & particle shaping: Delivers exceptional performance in secondary reduction and particle shaping, specifically optimized for crushing medium-to-hard stones into high-quality aggregates.
Specification of mobile cone crusher:
| Model | AHP300L | AHP400L | ACH430 |
| Feeding machine | |||
| Specification | B1000*4.6m | B1200*4.6m | B1000*6.5m |
| Drive mode | Inverter motor | ||
| Reducer drive | |||
| Cone crusher equipment | HP300 | HP400 | CH430 |
| Max feeding size | 200mm | 260mm | 185mm |
| Minimum outlet | 10mm | 20mm | 20mm |
| Hydraulic tracked chassis | 60T | 60T | 60T |
| Boat frame | Q345B welding | Q345B welding | Q345B welding |
| Return screen specification | 2YZK1500*3500 | YK1500*3800 | YK1530 |
| Drive mode | Vibration Motor 3.7KW | Vibration Motor 3.7KW | Vibration Motor 3.7KW*2 |
| Main belt conveyor specification | B1200*12.5m | B1200*10.6m | B1200*10.6m |
| Drive mode | Motor reducer drive 15KW | Motor reducer drive 15KW | Motor reducer drive 15KW |
| Under the screen belt conveyor specification | B1200*5.6m | B1200*6.2m | B1200*5.4m |
| Drive mode | Motor reducer drive 7.5KW | Motor reducer drive 7.5KW | Motor reducer drive 7.5KW |
| Return belt conveyor specification | B500*12.5m | B650*12.5m | B500*12.5m |
| Drive mode | Motor reducer drive 7.5KW | Motor reducer drive 7.5KW | Motor reducer drive 7.5KW |
| Transfer belt conveyor specification | B500*2.4m | B650*2.4m | B500*2.4m |
| Drive mode | Motor reducer drive 4KW | Motor reducer drive 4KW | Motor reducer drive 4KW |
| Electric control cabinet | The cone crusher motor starts with variable frequency, the feeder starts with variable frequency, and other motors start directly. | ||
| Belt conveyor folding cylinder | Hydraulic automatic lift | ||
| Hydraulic pumps, valves, accessories | Load sensitive, electric-hydraulic proportional manifold | ||
Materials processed by mobile cone crusher
Basalt
Granite
Limestone
Concrete blocks
Pebble
Quartz
Copper ore
Gold ore
Iron ore
Steel slag
Andesite
Asphalt pavement
Versatile applications for mobile cone crusher
ASTON mobile cone crushing plant are built to handle high-throughput secondary crushing across demanding quarrying and mineral processing applications.
By enabling efficient closed-circuit recirculation on-site, this equipment helps significantly reduce intermediate transport steps while supporting high daily yields of tight-spec aggregates.
CN:
Typical application areas
Mining & mineral processing:
Secondary crushing of hard metallic and non-metallic ores—such as iron ore, copper ore, quartz, and granite—delivering uniform feed sizes for downstream milling operations.
High-grade aggregate production:
Precision secondary reduction for river pebbles, basalt, and diabase to produce high-density, cubical aggregates essential for high-standard concrete and asphalt.
Infrastructure & highway engineering:
On-site fine crushing and shaping of limestone, andesite, and crushed stone chips to meet strict gradation standards for road base layers and bridge construction.
Manufactured sand preparation:
Fine reduction and particle shaping of quartz-rich rocks and quarry stone dust, converting low-value rock fragments into high-value manufactured sand.
Explore industrial applicationsWorking process of mobile cone crusher
The working process of our ASTON mobile cone crushing plant begins with precise, uniform feeding, transitions into high-pressure laminated crushing within our hydraulic cone host, and concludes with efficient closed-circuit discharge. Designed with built-in hydraulic overload protection and automated return conveyors, we ensure seamless material flow, maximum particle shape quality, and continuous operational safety for your site.
The heavy-duty feeder smoothly receives pre-crushed materials from primary units or surge hoppers. Integrated load-sensing controls continuously regulate feed speed, ensuring a consistent choke-feed condition for optimal crushing chamber efficiency.
Before entering the crushing cavity, integrated pre-screening decks separate natural fines and already-qualified aggregates. By bypassing non-sized particles, the system prevents over-grinding, minimizes liner wear, and optimizes overall energy efficiency.
Materials are crushed under high pressure between the mantle and concave using advanced inter-particle compression, producing highly cubical aggregates. In the event of tramp iron or uncrushable debris, the hydraulic overload system automatically releases and resets without halting operations.
The crushed output is smoothly collected and transferred via a heavy-duty discharge conveyor equipped with adjustable discharge heights. Optimized material acceleration ensures minimal spillage, lower dust generation, and steady flow to downstream equipment.
Outflowing aggregates pass through an integrated return screen to ensure precise particle size classification. Oversize material is automatically recirculated back into the cone host for re-crushing, guaranteeing 100% aggregate compliance with strict specs.
